NEC 504 addresses the installation of intrinsically safe equipment in hazardous locations.
Relation to UL
The selection and configuration of equipment in accordance with the specifications of NEC 504 form the basis for the technical design of the control cabinet. Therefore, the NEC 504 specifications should be taken into account as early as the system design phase.
What is NEC 504?
Article 504 of the National Electrical Code provides the legal framework for the installation of intrinsically safe equipment in so-called hazardous locations—that is, areas at risk of explosion, as defined in NEC 500. Before we take a closer look at the individual provisions, let’s briefly discuss what “intrinsic safety” actually means.
Intrinsic Safety vs. External Safety
For a fire —or even an explosion —to occur, three conditions must occur simultaneously:
- a fuel, such as a flammable gas or flour dust
- an oxidizing agent, usually oxygen
- and an ignition source, such as a hot surface or a spark caused by a short circuit
Most explosion protection measures are essentially aimed solely at preventing these three components from coming together. Since the presence of explosive fuel-air mixtures cannot always be avoided, explosion protection in the relevant areas must focus on the ignition sources. There are two options for this purpose.
Various Explosion Protection Measures According to the NEC
First, a potential ignition source can be isolated from the ambient air. In the case of control cabinets, this is usually achieved through sealed enclosures and/or by purging the interior of the cabinet with an inert gas. Second, the control cabinet can be designed to be intrinsically safe.
In an intrinsically safe control cabinet, the formation of an ignition source is prevented. This is achieved by designing the system so that it cannot, at any time, release enough energy (e.g., in the form of intense heat or sparks) to ignite any present fuel.
An intrinsically safe system is generally a complete system consisting of intrinsically safe devices in hazardous areas and non-intrinsically safe devices in non-hazardous areas, as well as their electrical connections. The specific requirements for intrinsically safe devices and circuits in these systems are governed by Article 504 of the National Electrical Code (NEC). Article 500 of the National Electrical Code , on the other hand, defines the classification of hazardous locations based on the type and severity of the explosion hazard.
Questions about UL?
Our experts are here to help you, whether you need a quick answer or detailed information.
What are the most important provisions of NEC 504?
NEC 504 contains numerous specific provisions on how to ensure intrinsic safety in electrical equipment. Therefore, the following provides only a brief overview of the most important regulations.
Intrinsically Safe Circuits: How They Must Be Isolated
There must be no connection between intrinsically safe and non-intrinsically safe circuits. There must be a minimum distance of 50 mm between an intrinsically safe circuit and a non-intrinsically safe circuit, or a physical barrier must be installed, such as a partition made of insulating material or a grounded metal part. This is the key requirement of NEC 504.
Critical for intrinsic safety: Follow the wiring diagram
Components that are part of an intrinsically safe installation must be installed exactly as specified in the wiring diagram, because intrinsic safety relies largely on design features, not just on the selection of individual components. The minimum clearances mentioned above play a role here, as do many other factors that must be taken into account when designing a control cabinet.
Why the Equipment Grounding Conductor Is So Important
Intrinsically safe devices, their enclosures, metal cable conduits, etc., must be grounded via the Equipment Grounding Conductor (EGC). The EGC is a very low-resistance ground connection used to divert fault currents in the parts of the equipment that normally do not carry voltage. It must not be confused with other grounding devices, such as a grounding rod, since these have a significantly higher impedance.
What are the requirements for control cabinet enclosures under NEC 504?
If an enclosure contains only intrinsically safe devices or circuits, it does not need to be sealed against the ingress of ambient air. Nevertheless, there are also intrinsically safe control cabinets with tightly sealed enclosures. In such cases, however, the sealing is not intended to prevent the risk of explosion, but rather to protect the components from water and dust ingress.
Zusammenfassung
NEC 504 is a section of the National Electrical Code. It specifies the requirements for intrinsically safe equipment and circuits. If equipment is intrinsically safe, it may be operated in areas where an explosive atmosphere is present without the need for external explosion protection measures.
